Automatic Insertion Machine for PCB Assemblies

The automatic insertion machine streamlines through-hole component placement with ±0.02 mm precision, handling axial, radial, and DIP parts at more than 50,000 insertions per hour. Equipped with AI vision and self-learning algorithms, it ensures correct polarity and orientation, even for complex multi-layer boards. Modular feeders and quick-change tooling enable product changeovers in under five minutes, making the auto insertion machine ideal for high-mix automotive, industrial, and telecom production. Compliant with IPC-610 and ISO 9001 standards, it reduces defects by up to 95% while cutting labor costs by 70%. Energy-efficient and IoT-enabled, it integrates seamlessly into smart factories, delivering 24/7 reliability for mission-critical electronics where speed, accuracy, and scalability drive manufacturing excellence.

CONTACT US

Increase Productivity with Automatic Insertion Machine for PCB Assemblies

This machine achieves 100,000+ insertions/hour with AI-powered self-optimization, delivering ±0.003mm precision for micro-connectors and high-density boards. Real-time 3D vision corrects component skew mid-insertion, ensuring zero defects. Modular, tool-free feeders enable<30-second product changeovers, while IoT analytics predict jams and optimize workflows.

Energy-efficient motors slash power use by 50%, aligning with ESG goals. Compliant with automotive AEC-Q200 and medical ISO 13485, it’s trusted for 5G, EV charging systems, and surgical devices. By merging unmatched speed, self-learning agility, and sustainable operations, it redefines productivity for next-gen electronics—where innovation meets uncompromising reliability.

How an Automatic Insertion Machine Streamlines Through-Hole Component Placement?

This machine by the SMT line factory simplifies through-hole assembly with AI-guided precision, placing components at 120,000+ insertions/hour while adapting to complex PCB layouts in real time. Vision systems and auto-calibrating grippers eliminate misalignments, even on multi-layer or high-density boards. Tool-free feeder swaps enable<20-second product changeovers for high-mix flexibility.

Integrated defect detection reduces rework by 90%, and energy recovery cuts power use by 45%. Compliant with IPC-A-610 and automotive IATF 16949, it ensures flawless assembly for EV powertrains, medical monitors, and telecom infrastructure—where speed, adaptability, and zero-error placement transform labor-intensive tasks into seamless, scalable workflows.

Automatic Insertion Machine vs SMT Pick and Place Machine

Comparison Item	Automatic Insertion Machine	SMT Pick and Place Machine	How to Choose
Component type	Through-hole components: radial, axial, DIP, connectors	Surface-mount devices: chips, ICs, BGAs, QFNs, LEDs	Choose based on whether components require lead insertion or surface placement.
Process position	DIP/THT assembly before wave soldering or selective soldering	SMT assembly before reflow soldering	Hybrid factories may need both SMT and THT equipment.
Main value	Reduce manual insertion and improve through-hole consistency	Increase high-speed component mounting capacity	Match equipment to actual product BOM and production volume.
Typical line	Insertion machine → wave soldering → inspection	Solder paste printer → pick and place → reflow oven → AOI	CY can configure full SMT, DIP or hybrid lines.

If your PCB assembly includes both SMD and through-hole components, CY Industry can help evaluate whether you need an SMT placement line, a THT automatic insertion machine, or a hybrid SMT + DIP assembly line.

How to Choose an Automatic Insertion Machine

Selection Factor	What Buyers Should Check	Why It Matters
Component type	Radial, axial, DIP, connector, terminal or odd-form components	Determines feeder type, tooling and insertion method.
PCB size and layout	Maximum board size, thickness, panel layout and component density	Ensures the machine can handle the board and support stable insertion.
Insertion volume	Daily output target, product mix and line takt time	Helps choose between flexible production and higher-volume configurations.
Feeding method	Tape, tube, tray, bowl or customized feeding	Affects changeover speed and production stability.
Tooling and fixtures	Custom fixture design, board support and insertion force control	Critical for connectors, terminals and odd-form components.
Line integration	Conveyor, wave soldering machine, selective soldering, AOI/X-ray	Ensures the equipment works as part of a complete PCB assembly process.
Service support	Installation, training, spare parts and remote troubleshooting	Reduces downtime after machine delivery.

Send us your PCB drawing, component list, target output and current production process. CY Industry can recommend a suitable automatic insertion machine and matching automated insertion equipment for your PCB assembly line.

FAQs about Automatic Insertion Machine

What information should I send to get a machine recommendation?

Please send your PCB drawing, component list, expected output, current process, factory layout and destination country so CY Industry can recommend the right machine configuration.

What is an automatic insertion machine used for?

An automatic insertion machine is used to insert through-hole components such as radial components, axial components, DIP parts, connectors and terminals into printed circuit boards automatically.

What is the difference between an automatic insertion machine and an SMT pick and place machine?

An SMT pick and place machine places surface-mount components on the PCB surface, while an automatic insertion machine inserts through-hole components into PCB holes before soldering.

How do I choose an auto insertion machine for PCB assemblies?

Buyers should check component type, PCB size, insertion volume, feeding method, tooling requirements, line integration and service support before choosing an auto insertion machine for pcb assemblies.

Can CY Industry provide a complete THT or DIP assembly line?

Yes. CY Industry can configure automated insertion equipment, PCB handling systems, wave soldering machines, selective soldering equipment and inspection machines for a complete THT or DIP assembly line.

What affects automatic insertion machine price?

Price depends on component type, feeder configuration, tooling, PCB size, machine configuration, inspection options and whether the equipment is integrated into a complete assembly line.
