Specifications | ||||
Model | CY-250B | CY-330B | CY-390B | CY-460B |
External dimensions | 1680x765x1200mm | 1900x845x1200 | 2160x905x1200 | 2400x980x1300 |
PCB board size | 50-250mm | 50-330 | 50-390 | 50-460 |
PCB transportation direction | L-R | |||
Magazine size | 330x250x563mm | 450x330x563mm | 550x390x570mm | 550x460x570 |
Magazine lifting step distance | 10,20,30,40mm | |||
Working height | 900±20mm | |||
Control mode | PLC+touch screen | |||
Power supply | AC220V/50-60HZ | |||
Working pressure | ≥0.4MP | |||
Single chip microcontroller control, stable and reliable operation;
Ultra thin button control with indicator light, easy to operate;
Multiple sound and light alarm functions
Can use standard material racks, with strong universality
The lifting step distance of the material rack can be set according to the thickness of the PCB
Equipped with signal communication interfaces, it can be connected to other machines online.
